Wall-to-Wall

Product Code	Joint Gap (a)	Total Movement	Parapet Width (b)	Height (h)	Top Surface Width (s)
AR281 – 050	50 mm	± 40 mm	150 mm	13 mm	150 mm
AR281 – 100	100 mm	± 50mm	250 mm	13 mm	250mm
AR281 – 150	150 mm	± 65mm	300 mm	13 mm	300mm
AR281 – 200	200 mm	± 65mm	350 mm	13 mm	350mm
AR281 – 250	250 mm	± 65mm	400 mm	13 mm	400 mm

Wall-to-Corner

Product Code	Joint Gap (a)	Total Movement	Parapet Width (b)	Height (h)	Top Surface Width (s)
AR281 – 050K	50 mm	± 40 mm	100 mm	13 mm	100mm
AR281 – 100K	100 mm	± 30mm	175 mm	13 mm	175mm
AR281 – 150K	150 mm	± 30mm	225 mm	13 mm	225mm
AR281 – 200K	200 mm	± 30mm	275 mm	13 mm	275mm
AR281 – 250K	250 mm	± 30mm	325 mm	13 mm	325mm

Contact us for more information.
