Floor-to-Floor

Product Code	Joint Gap (a)	Total Movement	Parapet Width (b)	height (h)	Load	Top Surface Width (s)
AR 804-100	100 mm	± 50 mm	276 mm	70 mm	Walker / Hand Pallet Lifter	356 mm
AR 804-150	150 mm	± 75mm	326 mm	70 mm	Walker / Hand Pallet Lifter	406mm
AR 804-200	200 mm	± 75mm	490 mm	70 mm	Walker / Hand Pallet Lifter	571mm
AR 804-250	250 mm	± 75mm	540 mm	70 mm	Walker / Hand Pallet Lifter	621mm
AR 804-300	300 mm	± 75mm	590 mm	70 mm	Walker / Hand Pallet Lifter	671 mm

Floor-to-Wall

Product Code	Joint Gap (a)	Total Movement	Parapet Width (b)	height (h)	Load	Top Surface Width (s)
AR 804-100K	100 mm	± 50 mm	188 mm	70 mm	Pedestrian / Cleaning Machine	228 mm
AR 804-150K	150 mm	± 50 mm	260 mm	70 mm	Pedestrian / Cleaning Machine	299 mm
AR 804-200K	200 mm	± 50 mm	346 mm	70 mm	Pedestrian / Cleaning Machine	386 mm
AR 804-250K	250 mm	± 50 mm	396 mm	70 mm	Pedestrian / Cleaning Machine	436 mm
AR 804-300K	300 mm	± 50 mm	446 mm	70 mm	Pedestrian / Cleaning Machine	486 mm
