Khe co giãn AR-606-Seri-congtyLK

Roof-to-Roof

Technical drawing of roof-to-roof expansion joint
Product CodeJoint Gap
(a) 		Total Movement
Parapet Width (b)		 Top Surface Width (s)
AR606-050 50 mm ± 25 mm 150mm 386mm
AR606-100 100 mm ± 50mm 150mm 436mm
AR606-150 150 mm ± 50mm 150mm 486mm
AR606-200 200 mm ± 50mm 150mm 536mm
AR606-252 250 mm ± 50mm 250mm 776 mm
Technical specifications table for roof-to-roof joints

Roof-to-Wall

Technical drawing of roof-to-wall expansion joint
Product CodeJoint Gap
(a) 		Total MovementParapet Width (b)Top Surface Width (s)
AR606-050K 50 mm ± 40 mm 150mm 218mm
AR606-100K 100 mm ± 50mm 150mm 268mm
AR606-150K150 mm ± 65mm 150mm 318mm
AR606-200K 200 mm ± 65mm 150mm 368mm
AR606-252K 250 mm ± 65mm 250mm  513mm
Technical specifications table for roof-to-wall expansion joints

Contact us for more information.
